Resume

KzDialogue is a modular, data-driven dialogue and subtitles system for Unreal Engine 5. It is built around a clean separation between data, playback engine, and presentation, so that lines, audio, subtitles, cinematics, and gameplay events can all be driven from the same authored asset.

It ships with a custom asset editor, a Sequencer track for cinematic dialogue, and an example UMG subtitle widget. The runtime is presentation-agnostic: you can swap or stack views (subtitles, history log, 3D worldspace billboards, accessibility captions) on top of the same player.

Repository: https://github.com/kirzo/KzGameplay

⚠️ Dependencies & Installation

This plugin relies on the following custom module to function:

  • KzLib: Core math and utility libraries.

Installation Steps

  1. Navigate to your Unreal Engine project's root directory.

  2. If it doesn't exist, create a folder named Plugins.

  3. Clone or download this repository and its dependencies into the Plugins folder. Your directory structure should look like this:

    YourProject/
└── Plugins/
    ├── KzDialogue/
    └── KzLib/

  4. Right-click your project's .uproject file and select Generate Visual Studio project files (or your IDE's equivalent).

  5. Open your IDE and compile the project, or simply launch the .uproject file to let Unreal Engine build the missing modules.

  6. Ensure the plugins are enabled in your project via Edit → Plugins.

🌟 Core Systems

🗂️ Authoring (UKzDialogueAsset)

A UPrimaryDataAsset describing a dialogue as an ordered list of lines. Each line carries:

  • Speaker: a FGameplayTag identity plus an optional display name override.
  • Localizable text (FText) and an optional USoundBase audio clip.
  • Explicit duration, with fallback to the audio length and finally to a default.
  • Tags (FGameplayTagContainer) for mood, intent, channel hints, etc.
  • Audio params (FInstancedPropertyBag) forwarded to the spawned UAudioComponent (bool, int, float, name, object, sound wave).
  • Actions (UKzDialogueAction, Instanced) that fire on line start/end without coupling the core to specific gameplay code.

Each line has a stable FGuid ID, automatically generated and preserved across edits and duplications, so external references (Sequencer sections, save data) survive reorders.

🎙️ Providers

UKzDialogueProvider is the abstract source of lines consumed by the player. Two implementations ship out of the box:

  • UKzAssetDialogueProvider: linear playback of a UKzDialogueAsset, with optional start/end line clamps.
  • UKzManualDialogueProvider: ad-hoc single line, ideal for system messages and barks.

The contract supports branching (GetChoices / SelectChoice) for future graph-based providers.

🎬 Player (UKzDialoguePlayer)

The engine of the system: a non-widget UObject with an explicit state machine (Idle → Entering → LineEntering → LinePlaying → LineExiting → Exiting), audio management, line timing, and a clean event API.

  • Inversion of control: views drive their own animations and notify the player when ready (NotifyEnterFinished, NotifyLineEnterFinished, ...). Views without animations skip those phases automatically.
  • Commands: Play, Pause, Resume, Stop, Abort, Interrupt, Skip.
  • Multicast events: OnDialogueStarted/Finished, OnLineStarted/Finished, OnPaused/Resumed, plus per-phase view request events.

🎚️ Subsystem & Channels (UKzDialogueSubsystem)

A UWorldSubsystem that owns one player per channel (Dialogue.Main, Dialogue.Bark, Dialogue.System, ...) and arbitrates between requests using priority. Lower-priority dialogues are interrupted cleanly by higher-priority ones; equal-priority requests preempt the current one.

USub->PlayAsset(MyAsset, ChannelTag);
USub->PlayLine(MyLine, ChannelTag, /*Priority=*/10);
USub->StopChannel(ChannelTag);

🗣️ Speaker Component (UKzDialogueSpeakerComponent)

Attach to any actor that can speak. Provides:

  • A SpeakerTag and DisplayName queried at runtime.
  • Speak(Asset) / SpeakLine(Line) helpers that route through the subsystem on the speaker's default channel.
  • A per-world registry so other systems can resolve a speaker actor from its tag.

💬 Subtitle Widget (UKzSubtitleWidget)

A reference UMG view: binds to a UKzDialoguePlayer, renders its events as fade-in/out widget animations, and updates speaker/text labels. Auto-detects whether the player should wait for fade animations based on which BindWidgetAnim slots are populated, so simple widgets without animations work out of the box.

🎞️ Sequencer Integration

A native-feeling Sequencer track for cinematic dialogue:

  • UMovieSceneKzDialogueTrack: holds a reference to a UKzDialogueAsset and a target channel.
  • UMovieSceneKzDialogueSection: each section plays one specific line, identified by its stable FGuid (so asset edits don't silently break references).
  • Searchable line picker with filters by speaker, gameplay tags, and an option to hide lines already used in the track.
  • Display name automatically extends to Kz Dialogue (AssetName) when an asset is bound.
  • bSuppressAudio flag for cinematics that play their own audio track.

📚 Quick Start

Play a dialogue from gameplay

UKzDialogueFunctionLibrary::PlayDialogueAsset(this, MyDialogueAsset, ChannelTag);

Bark a single line from an NPC

UKzDialogueSpeakerComponent* Speaker = ...;
FKzDialogueLine BarkLine;
BarkLine.Text = FText::FromString(TEXT("I heard something."));
Speaker->SpeakLine(BarkLine);

Bind a subtitle widget to a channel

UKzSubtitleWidget* Widget = CreateWidget<UKzSubtitleWidget>(PlayerController, SubtitleWidgetClass);
Widget->AddToViewport();
UKzDialoguePlayer* Player = GetWorld()->GetSubsystem<UKzDialogueSubsystem>()->GetOrCreatePlayer(ChannelTag);
Widget->BindPlayer(Player);

Drive dialogue from a Sequencer cinematic

  1. Add a Kz Dialogue track to your Level Sequence.
  2. Set its DialogueAsset and Channel in the details panel.
  3. Click + Section on the track and pick a line from the searchable menu.
  4. Resize the section to control on-screen duration.

🧩 Extension Points

  • Custom views: subclass UKzSubtitleWidget or write a brand-new one — the player's event API doesn't care what the view is. Multiple views can listen to the same player.
  • Custom providers: subclass UKzDialogueProvider for branching graphs, runtime-generated dialogue, or middleware adapters (Wwise/FMOD).
  • Line actions: subclass UKzDialogueAction to attach gameplay side effects to lines (camera focus, VFX, GAS effects, quest progression) without polluting the core.

License

Released under the MIT License.
